Flat
Freddie 30

The Flat Freddie 30 extrusion is a close cousin of Downhill Dan 30, but with a squarer profile for a more architectural look. It also features a more efficient diffuser for maximum output. Utilising up to 26W per metre of LED strip, the profile is ideal for applications where maximum light output is key. A versatile system suitable for various mounting options, Flat Freddie 30 can be surface mounted, recessed and suspended. Both wire and rod suspension options are available and the cowling accessory for plastered ceilings and walls creates a beautiful trimless finish.

Features
  • Highly versatile and powerful downlighting.
  • Squarer profile and more efficient diffuser than his cousin, Downhill Dan 3o.
  • Made for general and task downlighting in kitchens, living rooms, dining rooms, reception counters, mirror lighting.
Additional Information
  • Customised lengths and configurations, made to measure.
  • New Zealand designed and made.
  • Uniform lighting (reduces or eliminates the appearance of LED ‘dots’ with opal diffuser).
  • Various LED strip colour temperature and wattage options.
  • Installation: Interior and exterior (with IP65 or IP67 rated LED strip).
  • Material: Aluminium body, PMMA diffuser, aluminum end caps.
  • Power Supply: 24V DC – remote driver options ranging from 6W up to 320W.
  • Dimming: Various options available including Casambi, DALI, 0-10V, DMX – please enquire.
Mounting Options
  • Ceiling mounted
  • Recessed
  • Rod suspended
  • Surface mounted
  • Wall mounted
  • Wire suspended
Diffuser Options
  • Satin PMMA
  • Prismatic
Profile Finish Options
  • Natural silver anodised
    $item['profile_finish_option']
  • Textured white powder coat
    $item['profile_finish_option']
  • Textured black powder coat
    $item['profile_finish_option']
  • Custom powder coat colours
    $item['profile_finish_option']

LED Strip Options

Please take particular care when selecting LED strips as not all options are available for all profiles. Click on each LED strip series below to display the options suitable for the profile.

Other LED strip options may be available upon request. Please consult your local distributor for further information.

All LED strip lumen values mentioned in the tables below refer to source lumens (bare LED strip). Losses through diffuser/profile are not represented. Please consult photometric data for delivered lumen values.

Please note that for dimmable applications, our LED strips should be used with dimming controllers or drivers with a PWM frequency of 2000Hz or less in order to maintain warranty.

Super Series

Super Series
Our top-of-the-range and most versatile strip, suitable for almost any application.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SUPER-03-27
SUPER-03-30
SUPER-03-40
3W
2700K
3000K
4000K
310
330
345
144
10M
IP20, IP54, IP67
SUPER-07-27
SUPER-07-30
SUPER-07-40
7W
2700K
3000K
4000K
760
800
840
144
10M
IP20, IP54, IP67
SUPER-14-27
SUPER-14-30
SUPER-14-40
14W
2700K
3000K
4000K
1520
1600
1680
144
6M
IP20, IP54, IP67
SUPER-20-27
SUPER-20-30
SUPER-20-40
20W
2700K
3000K
4000K
1955
2060
2160
126
7M
IP20, IP54
SUPER-26-27
SUPER-26-30
SUPER-26-40
26W
2700K
3000K
4000K
2400
2530
2650
126
5M
IP20, IP54
For IP54 versions, add "-IP54" to end of codes above. Example code SUPER-07-40-IP54.
For IP67 versions, add "-IP67" to end of codes above.
IP54 and IP67 version reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10%. Colour temperature tolerance +/- 5%.
Download: Super Series LED Strip

Spec Series General

Spec Series General
Our general-purpose LED strip is a cost-effective solution for an array of interior and exterior uses including joinery.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-07-30
SPEC-07-40
7W
3000K
4000K
760
800
128
5M
IP20, IP67
SPEC-14.4-30-140
SPEC-14.4-40-140
14.4W
3000K
4000K
1150
1180
140
5M
IP20, IP67
SPEC-15-30
SPEC-15-40
15W
3000K
4000K
1425
1500
126
5M
IP20, IP67
For IP67 versions, add “-IP67” to end of codes above. Example code: SPEC-14.4-30-140-IP67.
IP67 versions reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.
Download: Spec Series General LED Strip

Spec Series Long

Spec Series Long
Spec Series Long allows single lengths of strip of up to 20m long from a single feed.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-11-30-LONG
SPEC-11-40-LONG
11W
3000K
4000K
690
710
120
20M
IP20, IP67
For IP67 versions, add “-IP67” to end of codes above. Example code: SPEC-11-30-LONG-IP67.
IP67 versions reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.
Download: Spec Series Long LED Strip

Spec Series Colour

Spec Series Colour
Spec Series Colour LED strips offer fixed colour options of red, green and blue.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-9.6-R
SPEC-9.6-G
SPEC-9.6-B
9.6W
RED
GREEN
BLUE
240
720
180
120
5M
IP20, IP65
For IP65 versions, add “-IP65” to end of codes above. Example code: SPEC-9.6-B-IP65.
IP65 versions reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.
Download: Spec Series Colour LED Strip

Spec Series TUNEABLE WHITE

Spec Series TUNEABLE WHITE
Spec Series colour tuneable white LED strip offers super-close pitch and high-out tuneable white options from 1800K to 5000K
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-19.2 -CTUNE
SPEC-20 -CTUNE
19.2W
20W
1800-5000K
1800-5000K
1200 - 1500
1500 - 1850
288
196
5M
5M
IP20
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.
LED pitch figures refer to LEDs of a single colour.
Lumen figures above apply at 3000K-4000K colour selections.
SPEC-19.2-CTUNE is 620lm at 1800K and 850lm at 5000K.
SPEC-20-CTUNE is 750lm at 1800K and 980lm at 5000K.
Download: Spec Series Tuneable White LED Strip

Spec Series RGB

Spec Series RGB
Spec Series colour tuneable white LED strip offers super-close pitch and high-out tuneable white options from 1800K to 5000K
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-15-RGB
15W
Red/Blue/Green
1090
120
5M
IP20, IP67
For IP67 versions, add “-IP67” to end of codes above. Example code: SPEC-15-RGB-IP67.
IP67 versions reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.
Download: Spec Series RGB LED Strip

Spec Series RGBW

Spec Series RGBW
Spec Series RGBW is a high-density RGBW strip with a pitch of only 8.3mm.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-14.4-RGB- 9.6-30
14.4W RGB, 9.6W White
RGB +3000K
810 White
120
5M
IP20
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance for white LEDs +/- 5%.
Download: Spec Series RGBW LED Strip

SPEC SERIES RGB+TWIN WHITE

SPEC SERIES RGB+TWIN WHITE
Spec Series RGBW is a high-density RGBW strip with a pitch of only 8.3mm.
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Max. length per feed
Protection
SPEC-15-RGB-25-2X30
SPEC-15-RGB-25-2X40
15W RGB, 25W White
RGB +3000K
RGB+4000K
1990 White
2100 White
4M
IP20, IP65
For IP65 versions, add “-IP65” to end of codes above. Example code: SPEC-15-RGB-25-2X30-IP65.
IP65 versions reduce above stated lumen figures by 5%.
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance for white LEDs +/- 5%.
Download: Spec Series RGB+Twin White LED Strip

Joining and Mounting Accessories

Straight joiner

JN-ST-12

90 degree joiner

JN-90-12

Mounting clip

MC-30

Cable base 60, recessed

CB-60-R-S (silver) / CB-60-R-W (white) / CB-60-R-B (black)

Cable base 80, surface mount

CB-80-SM-S (silver) / CB-80-SM-W (white) / CB-80-SM-B (black)

Wire suspension

SWK-1-1M (1 metre) / SWK-1-2M (2 metre) / SWK-1-4M (4 metre)

Suspension rod – 0.5m, 1m, 2m

ROD-0.5M / ROD-1M / ROD-2M

Recessed rod suspension kit (rod not incl.)

SRK-1-S (Silver) / SRK-1-W (White) / SRK-1-B (Black)

Surface mounted rod suspension kit (rod not incl.)

SRK-6-S (Silver) / SRK-6-W (White) / SRK-6-B (Black)

Recess cowling for plasterboard – 2m long

C-30-I

Recess cowling end cap for plasterboard

C-30-EC-I

Wall bracket

WB-DD30

Corner recess cowling for plasterboard – 2m long

C-30-CNR-2M

Corner metal recess cowling end cap

C-30-CNR-EC

Cowling joiner

C-30-JN

Specification Sheet

Flat Freddie 30

Installation Instructions

Wire suspended
Rod suspended
Metal cowling trimless recessed
Corner Cowling Recessed
Mounting clip surface mounted
Screw-fix surface mounted
Wall mounted

Photometric File

Photometric tests are conducted with a 500mm long LED strip, inside a silver anodised profile and diffuser as mentioned in the file.

Please note that black or dark powder coated extrusions will reduce delivered lumens by approximately 10%.

Please consult your local distributor if you require assistance with photometric files.

FF30 with SPEC-20-CTUNE
FF30 with SUPER-26-40

BIM Files

Flat Freddie 30 (ArchiCad)
Flat Freddie 30 (Revit)
